Secador de tolva de plástico de alta eficiencia para la industria del moldeo por inyección
Parámetros de la máquina secadora de tolva de plástico
| Modelo | ZL-25KG | ZL-50KG | ZL-75KG |
| Potencia de calefacción | 3 kW | 4 kW | 6 kW |
| Potencia del ventilador | 135 W | 150 W | 210 W |
| Volumen | 25 kg | 50 kilos | 75 kg |
| Tamaño | 770*460*820MM | 900*580*950MM | 1000*680*1150MM |
| Peso neto | 32 kg | 45 kg | 55 kg |
| Nota | Las dimensiones y el peso indicados no incluyen el soporte triangular. Si necesita usar la máquina de forma independiente, se recomienda añadir un soporte. | ||
El secador de tolva de plástico es un dispositivo que se utiliza para secar partículas de plástico. Generalmente se utiliza junto con equipos de procesamiento de plástico, como máquinas de moldeo por inyección y extrusoras. Al calentar y hacer circular aire, el secador de tolva de plástico puede eliminar la humedad de las partículas de plástico y mejorar el rendimiento del procesamiento y la calidad del producto de los plásticos.
Un secador de plástico es un dispositivo que se utiliza para eliminar la humedad de las materias primas plásticas. Durante el procesamiento del plástico, la humedad excesiva puede afectar la calidad de los productos plásticos, provocando burbujas y defectos en la superficie. Utiliza métodos como calefacción y ventilación para evaporar el agua en gránulos de plástico, asegurando que el plástico pueda tener un buen rendimiento en procesos de moldeo posteriores, como moldeo por inyección y extrusión.
Los secadores de tolva industriales brindan soluciones profesionales de secado de materiales plásticos con sistemas de calefacción y ventiladores eficientes para la eliminación uniforme de la humedad, asegurando que las materias primas cumplan con los estándares de producción; su diseño centrado en la seguridad incluye protección confiable contra sobretemperatura para evitar riesgos operativos, mientras que las estructuras compactas con bases estables permiten una colocación segura, los tamaños y pesos de paquetes manejables simplifican el transporte y la instalación, lo que los hace ideales para secar pellets y gránulos de plástico en moldeo por inyección, extrusión y otros escenarios de procesamiento de plástico, con un rendimiento de grado industrial con potencia estándar para respaldar una producción estable y productos finales de alta calidad.
Overview The ZL-100T is a 100-ton (351.7 kW) industrial FRP counter flow cooling tower purpose-built for data center applications. ZILLION engineered this 100-ton counter flow cooling tower with CE ISO 9001:2015 certification and quality construction for long service life in demanding industrial environments. Key Specifications Cooling capacity: 351.7 kW (100 refrigeration ton) Water flow rate: 78.1 m3/h design flow Heat rejection: 5 deg C approach to wet-bulb at 27 deg C design Fan airflow: 700 CMM at 1450 mm fan diameter Motor power: 2.2 kW at 380V 3-phase 50 Hz Head loss: 21 kPa at design flow Dry weight: 500 kg, operating weight: 1690 kg Overall dimensions: H2570 x Dia2900 mm Design Features FRP counter-flow shell for corrosion resistance and 20-year service life Aluminum alloy fan blade for industrial duty IP55 Class F insulation for harsh industrial environments Counter flow design for maximum heat transfer efficiency and 3 deg C approach Low-drift eliminator reduces water loss to 0.01 percent of circulation Applications extra-large industrial reliability for extra-large industrial data center deployment supporting 351.7 kW heat rejection. 5 deg C wet-bulb approach at 27 deg C design condition supports server room chiller integration. ASHRAE TC 9.9 compliant for Class A1-A2 facilities. Compact 2570 x 2900 mm footprint fits distributed data center edge deployment. N+1 redundancy configuration supported. Contact ZILLION Today Get a quote for the ZL-100T cooling tower from ZILLION factory direct. Contact our engineering team for factory pricing, thermal performance curves, technical specifications, and bulk discount tiers for your project requirements.
Continuous-duty plastic processing requires a shredder that runs 24 hours per day, 7 days per week without unplanned downtime. The ZL-PC700 24/7 Industrial Plastic Crusher is built for that operating environment, with thermal monitoring, predictive maintenance alerts, and 22 kW motor rated for continuous-duty service.
Overview The ZL-20T is a 20-ton (70.4 kW) industrial FRP counter flow cooling tower purpose-built for cip pharmaceutical applications. ZILLION engineered this 20-ton counter flow cooling tower with CE ISO 9001:2015 certification and quality construction for long service life in demanding industrial environments. Key Specifications Cooling capacity: 70.4 kW (20 refrigeration ton) Water flow rate: 15.62 m3/h design flow Heat rejection: 5 deg C approach to wet-bulb at 27 deg C design Fan airflow: 160 CMM at 770 mm fan diameter Motor power: 0.55 kW at 380V 3-phase 50 Hz Head loss: 14 kPa at design flow Dry weight: 67 kg, operating weight: 300 kg Overall dimensions: H1900 x Dia1180 mm Design Features FRP counter-flow shell for corrosion resistance and 20-year service life Aluminum alloy fan blade for industrial duty IP55 Class F insulation for harsh industrial environments Counter flow design for maximum heat transfer efficiency and 3 deg C approach Low-drift eliminator reduces water loss to 0.01 percent of circulation Applications SS316L stainless steel upgrade option for sanitary tri-clamp connections. CIP cycle compatible at 80 deg C hot water sanitization per cGMP standards for biotech and pharmaceutical processes. 70.4 kW heat rejection supports clean utility loops for Water-for-Injection and purified water systems. FDA 21 CFR and ASME BPE compliant for bioprocessing equipment. Contact ZILLION Today Get a quote for the ZL-20T cooling tower from ZILLION factory direct. Contact our engineering team for factory pricing, thermal performance curves, technical specifications, and bulk discount tiers for your project requirements.
Overview The ZL-400T is a 400-ton (1407.0 kW) industrial FRP counter flow cooling tower purpose-built for agriculture food processing applications. ZILLION engineered this 400-ton counter flow cooling tower with CE ISO 9001:2015 certification and quality construction for long service life in demanding industrial environments. Key Specifications Cooling capacity: 1407.0 kW (400 refrigeration ton) Water flow rate: 312.1 m3/h design flow Heat rejection: 5 deg C approach to wet-bulb at 27 deg C design Fan airflow: 2400 CMM at 2700 mm fan diameter Motor power: 7.5 kW at 380V 3-phase 50 Hz Head loss: 36 kPa at design flow Dry weight: 2840 kg, operating weight: 5740 kg Overall dimensions: H3870 x Dia5600 mm Design Features FRP counter-flow shell for corrosion resistance and 20-year service life Aluminum alloy fan blade for industrial duty IP55 Class F insulation for harsh industrial environments Counter flow design for maximum heat transfer efficiency and 3 deg C approach Low-drift eliminator reduces water loss to 0.01 percent of circulation Applications SS316L food-grade stainless steel upgrade option for district cooling mega industrial HTST pasteurization (72 to 32 deg C pre-cooling) and chiller condenser loop (4 deg C chilled water final cooling). 1407.0 kW capacity supports 30,000 L/h milk processing lines. CE certified, FDA 21 CFR compliant materials. Suitable for brewery wort cooling, beverage production, and dairy processing operations. USDA-FSIS compliant for meat and poultry processing. Contact ZILLION Today Get a quote for the ZL-400T cooling tower from ZILLION factory direct. Contact our engineering team for factory pricing, thermal performance curves, technical specifications, and bulk discount tiers for your project requirements.
Overview The ZL-500T is a 500-ton (1758.5 kW) industrial FRP counter flow cooling tower purpose-built for hvac epc contractor applications. ZILLION engineered this 500-ton counter flow cooling tower with CE ISO 9001:2015 certification and quality construction for long service life in demanding industrial environments. Key Specifications Cooling capacity: 1758.5 kW (500 refrigeration ton) Water flow rate: 392.4 m3/h design flow Heat rejection: 5 deg C approach to wet-bulb at 27 deg C design Fan airflow: 2600 CMM at 2700 mm fan diameter Motor power: 7.5 kW at 380V 3-phase 50 Hz Head loss: 36 kPa at design flow Dry weight: 2900 kg, operating weight: 5800 kg Overall dimensions: H3870 x Dia5600 mm Design Features FRP counter-flow shell for corrosion resistance and 20-year service life Aluminum alloy fan blade for industrial duty IP55 Class F insulation for harsh industrial environments Counter flow design for maximum heat transfer efficiency and 3 deg C approach Low-drift eliminator reduces water loss to 0.01 percent of circulation Applications IP55 Class F insulation, CE ISO 9001:2015 certified for district cooling mega-capacity data center industrial HVAC chiller condenser water loop integration. 3870 x 5600 mm footprint fits standard equipment room layouts. Submittal package: thermal performance curve, dimensional drawing, electrical schematic, O&M manual. Project delivery 30-45 days for bulk orders. Compatible with BACnet and Modbus BMS integration. Bid-ready specifications for tender documents. Seismic certification package available. Contact ZILLION Today Get a quote for the ZL-500T cooling tower from ZILLION factory direct. Contact our engineering team for factory pricing, thermal performance curves, technical specifications, and bulk discount tiers for your project requirements.
La serie de productos de nuestra empresa es bien conocida en la industria de maquinaria auxiliar de plástico por su excelente rendimiento y alto costo.
